RAM Type Fix Frame Press Machine

Capacity	Bed Size (mm)	Bed to Ram (Delight Gap) (mm)	Stroke (Travel of Ram) (mm)	Shut Height	Motor H.P.	Oil Tank
20 Ton	508 x 305	350	100	250	3	150
30 Ton	558 x 355	350	100	250	3	150
50 Ton	800 x 400	400	125	275	5	200
60 Ton	800 x 450	400	125	275	5	200
80 Ton	800 x 500	450	125	325	7.5	250
100 Ton	900 x 500	450	150	300	7.5	250
150 Ton	1000 x 600	500	150	350	10	300
200 Ton	1000 x 650	600	150	450	15	300
250 Ton	1200 x 700	600	150	450	15	350
300 Ton	1200 x 700	650	175	475	20	400
400 Ton	1200 x 800	650	175	475	25	500
500 Ton	1250 x 800	650	175	475	30	600

Note: This Specification is Customize, we are making machine as per customers requirement.
