Technical Specifications
| Capacity | Between Column Length x Width (mm) | Between Ram To Bed (mm) | Stroke (Travel of Ram) (mm) | Motor H.P. |
|---|---|---|---|---|
| 5 Ton | 500 × 200 | 75 × 600 | 150 | 1 |
| 10 Ton | 600 × 200 | 75 × 600 | 200 | 1 |
| 15 Ton | 650 × 200 | 75 × 600 mm | 200 | 1.5 |
| 25 Ton | 850 × 300 | 180 × 910 | 200 | 1.5 |
| 40 Ton | 950 × 350 | 180 × 910 | 250 | 2 |
| 50 Ton | 1000 × 400 | 180 × 950 | 250 | 3 |
| 60 Ton | 1050 × 450 | 180 × 975 | 250 | 3 |
| 75 Ton | 1180 × 500 | 180 × 975 | 250 | 3 |
| 100 Ton | 1200 × 600 | 180 × 975 | 225 | 5 |
| 150 Ton | 1300 × 625 | 180 × 975 | 240 | 7.5 |
| 200 Ton | 1325 × 660 | 180 × 975 | 240 | 10 |
| 300 Ton | 1350 × 650 | 180 × 975 | 250 | 10 |
| 500 Ton | 1450 × 700 | 180 × 1000 | 260 | 15 |
Note: This Specification is Customize, we are making machine as per customers requirement.
